The Orbital Wash System, a feature of 24" SMEG dishwashers, consists of a double spray arm with contra-action rotation which distributes water evenly throughout the cavity. This ensures excellent wash quality, and a greatly-reduced noise level.
TYPE

Product Family:Dishwashers
Commercial height:86 cm
Number of place settings:13
Installation:Under counter built-in
Commercial width:60 cm
EAN code:8017709303747
AESTHETICS
Colour:Stainless steel
Front panel colour:Finger friendly stainless steel
LED/display colour:White
Buttons colour:Silver (oropal grey)
PROGRAMS / FUNCTIONS






N. of programmes:10+1
Soak:Yes
Express 27':Yes
Mix:Yes
Sterilise:Yes
Self clean:Yes
Delicate:Yes
Normal:Yes
Crystal & China:Yes
Eco express:Yes
Express 60':Yes
Pots & Pans:Yes
Washing temperatures:38, 45, 50, 55, 65, 70, 75 °F
OPTIONS




Dry Assist option:Yes
Delay timer option:Up to 24 hours
1/2 load FlexiZone option:Yes
Special programs option:Yes
BASKETS



N° baskets:3, FlexiDuo
Basket components colour:Grey
Upper Basket:With 1 foldable rack
Glass holder:Yes
Height adjustment of the upper basket:On three levels (5 cm)
Sliding Guides Extra Glide:Yes
Lower Basket:With 2 foldable racks
Largest loadable dish in upper basket:18,0 inches
Lower basket with anti-drip inserts:Yes
Largest loadable dish in lower basket:35,0 inches
Cutlery basket:Yes
Colour Inner Components:Blue
TECHNICAL FEATURES



Display:Delayed start, Programme time indicator, Time to end indication
Door opening system:Yes
Display type:LED (external)
On/off indicator:Yes
Salt light indicator:Light
Rinse aid indicator:Light
Progress indicator:Yes
End of cycle indicator:On display, with acoustic signal
Washing system:Orbital
Drying system:Natural condenser drying, with Dry Assist automatic door opening system at the end of the cycle
Motor:Single phase
Third spray arm:Single
Water softener:With electronic setting
Flood protection system:Total Acquastop
Max water hardness:100°fH;58°dH
Tub material:Stainless steel
Filter:Stainless steel
Concealed heating element:Yes
Hinges:Self balancing with variable hinges
Min. and max plinth height:98 - 168 mm
Adjustable feet:7cm, from 860 to 930 mm
PERFORMANCE / ENERGY LABEL

Noise level:48 dB(A) re 1pW
Annual energy consumption:255 KWh/year
Energy Star:Yes
ELECTRICAL CONNECTION
Connected power:1800 W
Current:10 A
Voltage:110-120 V
Type of connection:Single-phase
Frequency (Hz):60 Hz
Power supply cable length:140 "
LOGISTIC INFORMATION
Net weight (kg):110 lbs
Gross weight (kg):117 lbs
Country of origin:IT
Packed width:25 9/16 "
Packaged depth:26 3/8 "
Height (mm) packed:35 1/16 "
Dimensions of the packed product (mm):890X650X670
Maximum stackability:5
Type of packaging:Shrinkwrap
Packaging composition - paper & cardboard (kg):4 lbs
Packaging composition - polystyrene (kg):3 lbs
Other accessories:Salt funel
